Fagor Evo-Advance Pass-Through Dishwasher With Drain Pump AD-125HRS

Includes a detergent, rinse, and drain pump built right in.

HIGH TECHNOLOGY AVAILABLE TO ALL.

The E-VO CONCEPT is here for people who think simplicity and technology can coexist.

Product features

• Hood type dishwasher - EVO Generation - Advance range.
• With built in Heat Recovery System and energy recuperator
• The Heat Recovery System collects and condenses the steam during each cycle & is exhausted by the machine after a full cleaning cycle. It heats up the next cycle’s input water making it more energy efficient & with lower energy bills. It also eliminates the need of a ceiling exhaust canopy.
• Hourly production: 65 baskets/hour - 1170 dishes/hour.
• Clearance (max ware height): 440 mm.
• Wash cycles: 55"- 90" - 120".
• GLASS cycle: special program for washing glassware, based on the
• specifications of hygiene and safety standard DIN 10511. Cycle of 90
• seconds, with temperatures: 60 °C (wash) and 65 ºC (rinse).
• HRS: version with energy recuperator. HRS collects and condenses the
• steam exhausted by the machine after a full cleaning cycle, and heats up the
• input water. Power: 30 W.
• Made of stainless steel. Includes double skin
• insulated hood, external, front and side panels.
• Full double skin body and hood to isolate machine’s noise from the
• environment.
• Counterbalanced hood.
• Double rotating wash and rinse systems made of stainless steel, above and
• below.
• Tray filters on the tank, made of AISI-304 stainless steel.
• Two wash pumps, 600 W each.
• Rinsing pump: 260 W. Air break system.
• Drain pump: 70 W. Drainage cycle.
• Tank with 1.8 kW heating element.
• Tank capacity: 28 litres.
• Boiler with multipower heating elements: 3 / 4,5 / 6 / 9 kW.
• Boiler capacity: 9 litres.
• Water consumption: 2.4 litres/rinse.
• Thermostatic temperature control: washing at 60ºC and rinsing at 90ºC.
• Thermo stop system that guarantees minimum rinsing temperature of 85ºC.
• Safety thermostats.
• Built-in automatic rinse dispenser and detergent doser.
• Safety magnetic switch for hood opening.
• Adjustable legs.
• Water protection rating: IPX5
• Total power: adjustable: 4,2 ÷ 12,0 kW.
• Dimensions: 658 x 756 x 1540 mm.
• Height with HRS recuperator: 2.200 mm.
• Baskets equipment: 1 x CT-10, 1 x CP-16/18 and 8 cutlery containers.
• Warranty- 1 years parts & labour warranty
